Description

Hifi is a journey, not a destination.

I played piano, alto sax and clarinet, subscribe to the symphony, and enjoy the jazz and blues scenes in Seattle. I'm familiar with live music. My music interests span from classical to jazz, blues, and other stuff (rock, folk, funk, electronica, etc). Favorites include Michelangeli, Argerich, Furtwangler, Montoya, Piazzolla, Melvin Taylor, Junior Wells, Lionel Hampton, Jimmy Smith, Brubeck, Jeff Beck, Stanley Turrentine, Jeff Buckley, (early) Chicago, Zeppelin, Cream, Groove Armada, Massive Attack, Nightmares on Wax, Daft Punk, etc., depending on mood.

I've been interested in hifi since I was a kid. Pioneer in the 70s, Counterpoint in the 80s, Audio Research in the 90s... I grew cynical of the direction the hobby took in the 2000s. For this system, I wanted to express my personal sonic priorities beyond what is available in the commercial market. My goal is to communicate music's impact, soul, emotion, and nuance. I want my system to play with alacrity, gravitas, affection, protest, or just funkin' good times. If it can't conjure a wide range of emotional reactions, than it simply won't satisfy. After years of effort, this system plays small-scale music with softness and delicacy, while large-scale music like Rachmaninoff, Mahler and Zepplin is sublime, projected with bone-crushing power like a big Steinway D or Audi RS6.

Creating a memorable sound system is like cooking a delicious meal. In the beginning, I bought great ingredients, all the components and parts that comprise my playback. I quickly learned that ingredients without experience and talent aren't enough to create a memorable sound system. It took many years, failed experiments, and a few successes to get here.

Experiencing thoughtfully-implemented multi-way horns was an epiphany. My high points are Josh's wonderful Electronluv system at VSAC 2003, and Romy's Macondo in Boston.

The speakers are the heart and soul of my system. I named them Shibusa, a Japanese word describing an aesthetic of simple, natural beauty. Shibusa refers to things that exhibit: Elegant simplicity. Effortless effectiveness. Understated excellence. Beautiful imperfection. They began as Edgarhorns, purchased new in 2005. After years of learning, stupid mistakes, and epiphanies, I could write a book on horn speaker design and still barely scratch the surface. Horns are like F1 race cars - silly high performance under skilled hands, while unforgiving of fools (I made my share of foolish mistakes). My Edgarhorns evolved with the addition of stereo sub-bass channels (Danley Sound Labs horn subs, used in IMAX theaters), upper bass (full-size 142 hz tractrix horns from John Hasquin loaded with Fane Studio 8M drivers), mid-range (Coral M-100 drivers in 400 Hz tractrix horns), and HF (magnesium Fostex T500A Mk II), and crossovers and amps to support them. There is literally nothing leftover from the original Edgarhorns, but they were a great education.

There are a total of 10 drivers and channels (5 per side). All filters except sub-bass are first order, with both speaker-level and line-level filters. First order filters are beneficial to minimize phase spinning and other time domain pollution, but require better performing drivers due to more overlap between the drivers. Integrating all the horns, drivers, amps, and crossovers in my room was challenging, more difficult than I ever anticipated, and a required a very long learning curve. I use both measurements and subjective listening to balance speaker placement and individual channels. Listening room is 16' x 18'. The effortless and deep-bass, startling dynamics, and full-range clarity distinguish Shibusa from conventional speaker designs. There is NO harshness or 'horn' sound in Shibusa, according to visitors - even those with anti-horn bias.

Without the kind and generous support of horn thought-leaders like Dr. Bruce Edgar, John Hasquin, Steve Schell and Rich Drysdale, Romy, Jeffrey Jackson, and ESO, it would have been very difficult for me to achieve as much as I have. Thanks to all who shared in this journey!
Read more...

Components Toggle details

    • Shibusa Horn Speakers
    Having learned and designed these horns over a 6 year period, I could write a book....

    Shibusa is Japanese for the aesthetic of simple, natural, and unobtrusive beauty. The Shibui spirit captures my goals for music reproduction.

    4-way speaker system
    ~ 107dB sensitivity
    First-order crossovers
    Alnico magnets
    Time aligned

    HF: [greaterthansign]10kHz
    Fostex T500AMkII horn tweeter

    MF: [greaterthansign]800 Hz
    Coral M-100 compression drivers loading 600Hz tractrix horns

    Lower Mid Range: 120 - 800 Hz
    Fanse Studio 8M loading 142 Hz tractrix horns, built by John Hasquin. The horns are 30 inches in diameter, 27" deep, with 6" backchamber. They weigh around 140 pounds each. Sub-Bass: <100Hz Danley TH-SPUD tapped horn subs Crossover: 1st order Caps - Duelund and Mundorf SO Coils - Erse Copper foil (2005)
    • Lamm Industries ML-2 SET (modified)
    Dedicated 18 W SET for [greaterthansign] 100 Hz channels.

    Replaced unreliable, failure-prone stock 6C33C tube sockets with Johnson sockets.
    6/2013 Added a HP PLLXO filter to the input stage to remove large value caps from speaker level crossover and dump excess bass from the upper bass horn. Phil Marchand kindly and generously provided support with advice on how to best implement. Settled on a Rike 0.047uf for a first order filter at 77hz.
    10/4/2013
    - added -15dB voltage divider at input stage to match gain structure with high sensitivity system. The silence is absolute - can not tell if the system is powered on, even adjacent to speakers.
    - the divider network increased input impedance from 41k to 46k Ohms
    - increased cathode resistor value to 168k Ohms to improve V1 voltage regulator bias stability
    (2009)
    • Danley Sound Labs TH SPUD Subwoofers (x2)
    Two tapped horn subs. Crossed to main speakers via Dahlquist DQ-LP1 bass filter @3rd order, 85 Hz. Powered with Crown K2 power amplifier (2012)
    • Crown International K-2
    Dedicated subwoofer amplifier driving Danley tapped horns.

    500w/ch in to 8 ohms, damping factor [greaterthansign] 3,000 from 10 - 400 Hz.
    Bone crushing bass!
    (2013)
    • Dahlquist DQ LP-1 Sub Bass Filter (modified)
    Analog 3rd order low-pass filter for integrating subwoofers with main speakers.

    Modified with quieter, high capacity, outboard PSU, replaced plastic PC mount RCA sockets with sturdier chassis mount sockets, replaced signal caps with modern film caps

    Replaced Velodyne SMS-1 digital crossover (11/2013)
    • Lamm Industries L-1 Preamp (modified)
    Lamm's original linestage. Tube regulated and rectified power supply and solid-state signal path. I owned the two-box L2 at the same time and kept the L1 based on it's slightly warmer tone.

    Modified by replacing volume pot with a Goldpoint stepped attenuator.

    (2007)
    • Micro Seiki SX-8000 Turntable
    200 lb. turntable with 45 lb air-suspended platter and HS-80 high speed flywheel. The bass digs deep and punches as hard as granite. Supported on Vibraplane air suspension platform. (2009)
    • SME 3012R / Ortofon SPU-85 Limited (Stereo)
    SME 12" arm and limited edition SPU for stereo.
    • Micro Seiki MAX-282 / Denon 103S
    For non-pristine LPs
    • SME 3012 S2 Ortofon SPU (Mono)
    For mono LPs
    • Vibraplane 2210
    Vibration isolation platform beneath Micro Seiki TT (2013)
    • Bent Audio Mu / S & B TX-103 SUT Ag / Cu hybrid
    SUT, loaded @ 100R with SPU 85th Anniversary cartridge
    • Wright Sound WPP-100 Phono Stage (modified)
    Tube phono amp, separate tube regulated and rectified power supply, copper signal chassis, hand-assembled point to point construction.

    Dead quiet. Not super extended or transparent, but the midrange is beautiful. Very engaging and a joy to listen

    6/8/2014 further parts upgrades: 1) replaced tiny generic 0.1uf mica caps with Mundorf SIO 2) replaced tiny generic electrolytics with Elna Silmics. 5/17/2014 replaced tube rectifier with ss soft recovery diodes. Contrary to expectations, this resulted in very audible improvements in clarity, air, and bass. Will not be going back to the rectifier tube. 10/22/2013 upgraded input with nude Vishay TX2575 47k resistor and copper foil polystyrene 100pf cap
    Modified with Mundorf S/O output caps
    (2013)
    • Peerless 4611-8 / WE 618B SUT
    Rare, vintage, sublime-sounding line input transformers.
    • EAR 834PT (Thorsten-ized) Phono Stage (modified)
    Circuit mods and parts suggestions courtesy Thorsten Loesch: http://www.audioasylum.com/cgi/t.mpl?f=vinyl&m=108318 Implemented all of Thorsten's mods and replaced or removed around 75% of the stock parts. RIAA eq caps: Evox Rifa PFR and Nissei polystyrene Cu film, after living with silver mica. Coupling and output caps: V-Cap CuTF and Mundorf SO PS Caps: Nippon Chemi Con VX and Elna Silmic Resistors: Caddock Mk132 Highs are sweet and shimmery over a floor of bass. I like the balance of warmth, resolution and deep bass (post-mod), with a dash of raucousness the EAR brings. (2008)
    • Museatex BiDat Plus DAC (modified)
    Ed Meitner design DAC, upgraded by John Wright.

    10/20/2013 - removed 16 green ceramic bypass caps from PS.

    (2005)
    • Sonos Digital playback network
    Feeds DACs in both systems. Convenient. Not especially musical
    • Oppo BDP-83 Video
    Plays movies
    • PurePower APS 2000+
    Supplies regenerated power from dedicated 20A circuit to all compenents except Lamm ML-2s

    (2013)
    • Purist Audio Design Dominus (ICs and speaker wires)
    Pain to use due to ridiculous size, weight, and stiffness. Wonderful colorful tone and extended sound, effortless dynamics, with weight and texture. Anti-hifi.
    • Purist Audio Design Dominus Power Cable
    Wonderful - so natural and quiet.
    • Pranawire Satori Power Cables
    05-29-14 Terminated with Acrolink carbon fiber plugs. For Lamm ML2 power amps.
    • Klaudio Ultra-Sonic Record Cleaning Machine
    Contact-less record cleaner using ultra sound technology. No brushes or special fluids. Simply insert an LP, and the machine automatically cleans and vacuum drys. Feels sturdy as a brick.

    This is the most effective and easiest to use RCM in my experience.

    (2013)
    • Audio Control SA-3050A Real Time Analyzer Measurement Tool
    essential!
    • Holm Acoustics Holm Impulse Measurement Tool
    Windows-based measurement software for visualizing loudspeaker and room response
    • SMUG Fuzzmeaure Pro Measurement Tool
    Mac OS- based RTA software tool for visualizing loudspeakers and room response
    • Dedicated Power Circuits (analog, digital, power amps)
    added 3 new circuits to listening room
    • SRA Silent Running Audio VR Series isoBase
    Isolation platforms supporting Lamm ML-2s power amps, Lamm L-1 preamp, Yamaha B2 power amp, and Oppo DVD player
    • Various Equipment Stands SolidSteel, Zoethecus, Target, SRA
    Equipment racks: Zoethecus for digital gear SolidSteel for analog Target for PurePower regenerator

Comments 194

Owner
System edited: Added Audio Technica SS-300 platter mat

skushino

.
Scott,
.
I have been thinking of getting a super tweeter. Please let us know what your new tweeter does for your system.
.
Rgds,
Larry
.

cello

Owner
System edited: added Fostex T900A super tweeters, 8R impedence, 5-38kHz, 106dB sensitivity. Crossed over at 20kHz.

skushino

Owner
Larry-
You have shared your experience with many people here, and I appreciate your comment.

It's been a long journey, and today I'm about as far as could be from the original high-power low-efficiency set-up. It's been tons of fun!

skushino

Owner
Kleonard-
Well, you may be right. The transport is the only part of the system that I haven't experimented with. I'll have to get smarter on this. Thanks for your input.

skushino

.
Scott,
.
Great system and it's been a nice evolution to observe.
.
Congratulations on taking your time and thinking through a nicely integrated system. Love the direction you are headed. It's been fun watching your decisions.
.
Rgds,
Larry
.

cello

I have the DVP-9000ES also, and it is a horribly sounding transport. Believe it or not you could do better with a Denon DCM-370 ($300) cd player as a transport. If I were you I would experiment with better transports for cd playback. If your cd playback sounds so good now imagine how it will sound with a better transport. I use a Meridian 500, which is better than both, but I A/B ed the DVP-9000ES with the $300 DCM 370 (used $100) and it was no contest, the DVP-9000ES is that bad, (its very harsh and slow). Just a suggestion for something you might want to think about.

kleonard

Owner
System edited: Added Lamm L1 preamp to system. The L2 does wonderful things to playback. The sense of acoustic space, instrument scale and location, humanizing voice and "anti-electronic" signature is a treat. But there are some idiosyncracies about L2 playback that bother me. Specifically, the L2 has an upward tonal balance and a slight but noticable compression of dynamic range. Also, two full-size chassis is impractical. I want to evaluate the L1 in the hopes of retaining the L2 goodness, while addressing its problems.

skushino

Owner
System edited: Added EAR 834P phono corrector.

skushino

Owner
Oldiesrecordstr - thank you very much. Are you a record dealer?
scott

skushino

Owner
Sirspeedy - thanks for your nice comment, although sometimes I do have a BAD attitude ;-) Contact me when you come to Seattle, and we can arrange that listening session. I am sure we would have a blast...
scott

skushino

HI
Your system is super ++++++++

oldiesrecordstr

Skushino,what a wonderful attitude,and approach to the hobby you have.I'm sure a good listening session with you would be a blast.Only,I'll stay off the "bluffs"!!I don't like heights,other than in frequency!

[email protected]

Owner
System edited: Updated pictures

skushino

Scott,
We're getting the Khorns in a few weeks. Enjoy those Edgars
Howard

boa2

Owner
Howard, first impressions posted. Having fun and always learning. This is like an advanced course in speaker design and room acoustics. It takes some effort to get everything together.

How's the K-horns? Are you listening to them yet???

skushino

Owner
System edited: Added Edgarhorns to system. Position is limited by available space. Not even close to proper set-up. They are located outside of the Circes, almost at the sidewalls and 5 feet to the front wall, 10 feet to listening position. Exposed crossovers, wires everywhere, wooden horns temporarily supported by anything available, until furniture casing is built. My concern was not to lose the endearing strengths of the Circe, while gaining a sense of effortless agility and improving dynamic range. After getting past the kluged set-up and clutter, the first impression is promising. I'll keep it brief. Startling, effortless sound pressure gives a sense of aliveness and agility. The enitre room is pressurized with music information. This is not about loud, it's about loading the room in its entirety, even at low listening volume. Notes are separate, individual and organized. Still nice, round and warm rather than choppy and etched. Spatial information is about 80 - 90% of Circe - still very good. Room placement and optimization will take more lots of effort, based on size and weight. Much fun work yet to do!

skushino

Drumroll please..........
.......waiting for feedback on those Edgar babies!

boa2

Owner
System edited: Edgarhorns arrived today.

skushino

Owner
System edited: The Seismic Sub is in the system. This is my first experience using a sub-woofer. First, the tension bracing inside the back chamber had to be shaved for the 18" driver to fit properly. The amp arrived today, but w/o proper bass eq. Without eq, the sub system is not full-range, down to 20Hz. But does it really matter for music? Since the midrange drivers and horn haven't arrived yet, I am using the sub with my Circe speakers. My quick and dirty impression - small crossover and level adjustments have a large affect on sound. This will take some effort to optimize. Also, the mis-matched Welborne DRDs amps and Alon Circe speakers work better with sub reinforcement. It is 2:00am now, so it's time to get some sleep!

skushino

Owner
System edited: Bruce Edgar called today. Finally, he is testing the Vitavox S2 driver integration with the rest of the system. Initial results are looking good. He described the S2 as sounding very different from the stock JBL 2441 drivers, being sweeter and smoother. This is just what I wanted! I asked him to continue evaluation, testing the limits of performance on large-scale symphony music, and other demanding material. After many months, there is light at the end of the tunnel!

skushino

Owner
System edited: The Seismic Sub shell arrived yesterday. It ships in three separate pieces, so moving is easier than expected. Bruce is sweeping the 18" JBL driver, and plans to ship driver and Hsu plate amp this week. Also, I removed a free standing wood-burning fireplace from the listening room to make room for the sub. Bruce explained the tiled floor beneath the fireplace will provide an excellent boundary for the LF exhaust to enter the room.

skushino

Owner
System edited: The Edgar Seismic sub is scheduled to be delivered later this week. I decided to remove a wood burning stove to make room for this huge sub-woofer. The floor beneath the stove is ceramic tile, which will provide a boundary and reinforcement for the downward firing low freqs. The 80 Hz straight horns arrived a couple of weeks ago. Bruce is working on throat adapters for the Vitavox S2 midrange drivers. Fane ST5022 HF tweeters are purchased. My girlfriend thinks I'm nuts, but I know that she will be pleased after she listens to these horns.

skushino

Owner
Artg, Thanks for your comments! The Lamm works well for me. It has some issues - mostly some dynamic compression, upwards tonal balance, and two big chassis. These issues are balanced by super-precise spatial benefits. Positioning and sense of space are awesome! The Circes are my second Alon speakers. My first were Alon IIs purchased new in 1993. And I never feel the need to upgrade my little Meitner after listening to the Big Boys (DCS, EMM Labs, Lavry, Audio Aero, etc). It may not be the SOTA, but it's not embarrased either - it's a keeper...

skushino

Owner
System edited: My Museatex Bitstream returned today after servicing by John Wright. The data connection was randomly dropping signal due to a loose connection, so I sent the unit to John for repair. While it was in the shop, John replaced some of the caps with Black Gates. My Bitstream was already modified to Data II status, and for my ears, it was essential for digital playback. It really "vinalyzed" music. I really missed it! Just put it back into my system this afternoon, so I will withhold judgement until after break-in. My main concern is the BG caps do not screw-up the beautiful "rightness" of the DAC.

skushino
